고장코드중에서 PCM (엔진쪽만) 관련고장코드 일부이다. 엔진체크등이 어떻어요, 뭐가 고장일까요? 답은 아래중 하나이거나 혹 여러개의 고장코드가 있을것이다. 항상 먼저 진단부터 하는것이 좋은 이유이다.  Courtesy of https://dmv.de.gov/VehicleServices/inspections/pdfs/dtc_list.pdf

DTC Codes - P0100-P0199 – Fuel and Air Metering

1. P0100 Mass or Volume Air Flow Circuit Malfunction
2. P0101 Mass or Volume Air Flow Circuit Range/Performance Problem
3. P0102 Mass or Volume Air Flow Circuit Low Input
4. P0103 Mass or Volume Air Flow Circuit High Input
5. P0104 Mass or Volume Air Flow Circuit Intermittent
6. P0105 Manifold Absolute Pressure/Barometric Pressure Circuit Malfunction
7. P0106 Manifold Absolute Pressure/Barometric Pressure Circuit Range/Performance Problem
8. P0107 Manifold Absolute Pressure/Barometric Pressure Circuit Low Input
9. P0108 Manifold Absolute Pressure/Barometric Pressure Circuit High Input
10. P0109 Manifold Absolute Pressure/Barometric Pressure Circuit Intermittent
11. P0109 Intake Air Temperature Circuit Malfunction
12. P0111 Intake Air Temperature Circuit Range/Performance Problem
13. P0112 Intake Air Temperature Circuit Low Input
14. P0113 Intake Air Temperature Circuit High Input
15. P0114 Intake Air Temperature Circuit Intermittent
16. P0115 Engine Coolant Temperature Circuit Malfunction
17. P0116 Engine Coolant Temperature Circuit Range/Performance Problem
18. P0117 Engine Coolant Temperature Circuit Low Input
19. P0118 Engine Coolant Temperature Circuit High Input
20. P0119 Engine Coolant Temperature Circuit Intermittent
21. P0120 Throttle/Petal Position Sensor/Switch A Circuit Malfunction
22. P0121 Throttle/Petal Position Sensor/Switch A Circuit Range/Performance Problem
23. P0122 Throttle/Petal Position Sensor/Switch A Circuit Low Input
24. P0123 Throttle/Petal Position Sensor/Switch A Circuit High Input
25. P0124 Throttle/Petal Position Sensor/Switch A Circuit Intermittent
26. P0125 Insufficient Coolant Temperature for Closed Loop Fuel Control
27. P0126 Insufficient Coolant Temperature for Stable Operation
28. P0130 02 Sensor Circuit Malfunction (Bank I Sensor 1)
29. P0131 02 Sensor Circuit Low Voltage (Bank I Sensor I)
30. P0132 02 Sensor Circuit High Voltage (Bank I Sensor 1)
31. P0133 02 Sensor Circuit Slow Response (Bank 1 Sensor 1)
32. P0134 02 Sensor Circuit No Activity Detected (Bank I Sensor 1)
33. P0135 02 Sensor Heater Circuit Malfunction (Bank 1 Sensor 1)
34. P0136 02 Sensor Circuit Malfunction (Bank I Sensor 2)
35. P0137 02 Sensor Circuit Low Voltage (Bank I Sensor 2)
36. P0138 02 Sensor Circuit High Voltage (Bank I Sensor 2)
37. P0139 02 Sensor Circuit Slow Response (Bank 1 Sensor 2)
38. P0140 02 Sensor Circuit No Activity Detected (Bank 1 Sensor 2)
39. P0141 02 Sensor Heater Circuit Malfunction (Bank 1 Sensor 2)
40. P0142 02 Sensor Circuit Malfunction (Bank I Sensor 3)
41. P0143 02 Sensor Circuit Low Voltage (Bank I Sensor 3)
42. P0144 02 Sensor Circuit High Voltage (Bank I Sensor 3)
43. P0145 02 Sensor Circuit Slow Response (Bank 1 Sensor 3)
44. P0146 02 Sensor Circuit No Activity Detected (Bank I Sensor 3)
45. P0147 02 Sensor Heater Circuit Malfunction (Bank I Sensor 3)
46. P0150 02 Sensor Circuit Malfunction (Bank 2 Sensor I)
47. P0151 02 Sensor Circuit Low Voltage (Bank 2 Sensor I)
48. P0152 02 Sensor Circuit High Voltage (Bank 2 Sensor 1)
49. P0153 02 Sensor Circuit Slow Response (Bank 2 Sensor 1)
50. P0154 02 Sensor Circuit No Activity Detected (Bank 2 Sensor 1)
51. P0155 02 Sensor Heater Circuit Malfunction (Bank 2 Sensor 1)
52. P0156 02 Sensor Circuit Malfunction (Bank 2 Sensor 2)
53. P0157 02 Sensor Circuit Low Voltage (Bank 2 Sensor 2)
54. P0158 02 Sensor Circuit High Voltage (Bank 2 Sensor 2)
55. P0159 02 Sensor Circuit Slow Response (Bank 2 Sensor 2)
56. P0160 02 Sensor Circuit No Activity Detected (Bank 2 Sensor 2)
57. P0161 02 Sensor Heater Circuit Malfunction (Bank 2 Sensor 2)
58. P0162 02 Sensor Circuit Malfunction (Bank 2 Sensor 3)
59. P0163 02 Sensor Circuit Low Voltage (Bank 2 Sensor 3)
60. P0164 02 Sensor Circuit High Voltage (Bank 2 Sensor 3)
61. P0165 02 Sensor Circuit Slow Response (Bank 2 Sensor 3)
62. P0166 02 Sensor Circuit No Activity Detected (Bank 2 Sensor 3)
63. P0167 02 Sensor Heater Circuit Malfunction (Bank 2 Sensor 3)
64. P0170 Fuel Trim Malfunction (Bank 1)
65. P0171 System too Lean (Bank 1)
66. P0172 System too Rich (Bank 1)
67. P0173 Fuel Trim Malfunction (Bank 2)
68. P0174 System too Lean (Bank 2)
69. P0175 System too Rich (Bank 2)
70. P0176 Fuel Composition Sensor Circuit Malfunction
71. P0177 Fuel Composition Sensor Circuit Range/Performance
72. P0178 Fuel Composition Sensor Circuit Low Input
73. P0179 Fuel Composition Sensor Circuit High Input
74. P0180 Fuel Temperature Sensor A Circuit Malfunction
75. P0181 Fuel Temperature Sensor A Circuit Range/Performance
76. P0182 Fuel Temperature Sensor A Circuit Low Input
77. P0183 Fuel Temperature Sensor A Circuit High Input
78. P0184 Fuel Temperature Sensor A Circuit Intermittent
79. P0185 Fuel Temperature Sensor B Circuit Malfunction
80. P0186 Fuel Temperature Sensor B Circuit Range/Performance
81. P0187 Fuel Temperature Sensor B Circuit Low Input
82. P0188 Fuel Temperature Sensor B Circuit High Input
83. P0189 Fuel Temperature Sensor B Circuit Intermittent
84. P0190 Fuel Rail Pressure Sensor Circuit Malfunction
85. P0191 Fuel Rail Pressure Sensor Circuit Range/Performance
86. P0192 Fuel Rail Pressure Sensor Circuit Low Input
87. P0193 Fuel Rail Pressure Sensor Circuit High Input
88. P0194 Fuel Rail Pressure Sensor Circuit Intermittent
89. P0195 Engine Oil Temperature Sensor Malfunction
90. P0196 Engine Oil Temperature Sensor Range/Performance
91. P0197 Engine Oil Temperature Sensor Low
92. P0198 Engine Oil Temperature Sensor High
93. P0199 Engine Oil Temperature Sensor Intermittent

DTC Codes - P0200-P0299 – Fuel and Air Metering (Injector Circuit)

1. P0200 Injector Circuit Malfunction
2. P0201 Injector Circuit Malfunction - Cylinder 1
3. P0202 Injector Circuit Malfunction - Cylinder 2
4. P0203 Injector Circuit Malfunction - Cylinder 3
5. P0204 Injector Circuit Malfunction - Cylinder 4
6. P0205 Injector Circuit Malfunction - Cylinder 5
7. P0206 Injector Circuit Malfunction - Cylinder 6
8. P0207 Injector Circuit Malfunction - Cylinder 7
9. P0208 Injector Circuit Malfunction - Cylinder 8
10. P0209 Injector Circuit Malfunction - Cylinder 9
11. P0210 Injector Circuit Malfunction - Cylinder 10
12. P0211 Injector Circuit Malfunction - Cylinder 11
13. P0212 Injector Circuit Malfunction - Cylinder 12
14. P0213 Cold Start Injector 1 Malfunction
15. P0214 Cold Start Injector 2 Malfunction
16. P0215 Engine Shutoff Solenoid Malfunction
17. P0216 Injection Timing Control Circuit Malfunction
18. P0217 Engine Overtemp Condition
19. P0218 Transmission Over Temperature Condition
20. P0219 Engine Overspeed Condition
21. P0220 Throttle/Petal Position Sensor/Switch B Circuit Malfunction
22. P0221 Throttle/Petal Position Sensor/Switch B Circuit Range/Performance Problem
23. P0222 Throttle/Petal Position Sensor/Switch B Circuit Low Input
24. P0223 Throttle/Petal Position Sensor/Switch B Circuit High Input
25. P0224 Throttle/Petal Position Sensor/Switch B Circuit Intermittent
26. P0225 Throttle/Petal Position Sensor/Switch C Circuit Malfunction
27. P0226 Throttle/Petal Position Sensor/Switch C Circuit Range/Performance Problem
28. P0227 Throttle/Petal Position Sensor/Switch C Circuit Low Input
29. P0228 Throttle/Petal Position Sensor/Switch C Circuit High Input
30. P0229 Throttle/Petal Position Sensor/Switch C Circuit Intermittent
31. P0230 Fuel Pump Primary Circuit Malfunction
32. P0231 Fuel Pump Secondary Circuit Low
33. P0232 Fuel Pump Secondary Circuit High
34. P0233 Fuel Pump Secondary Circuit Intermittent
35. P0234 Engine Overboost Condition
36. P0235 Turbocharger Boost Sensor A Circuit Malfunction
37. P0236 Turbocharger Boost Sensor A Circuit Range/Performance
38. P0237 Turbocharger Boost Sensor A Circuit Low
39. P0238 Turbocharger Boost Sensor A Circuit High
40. P0239 Turbocharger Boost Sensor B Malfunction
41. P0240 Turbocharger Boost Sensor B Circuit Range/Performance
42. P0241 Turbocharger Boost Sensor B Circuit Low
43. P0242 Turbocharger Boost Sensor B Circuit High
44. P0243 Turbocharger Wastegate Solenoid A Malfunction
45. P0244 Turbocharger Wastegate Solenoid A Range/Performance
46. P0245 Turbocharger Wastegate Solenoid A Low
47. P0246 Turbocharger Wastegate Solenoid A High
48. P0247 Turbocharger Wastegate Solenoid B Malfunction
49. P0248 Turbocharger Wastegate Solenoid B Range/Performance
50. P0249 Turbocharger Wastegate Solenoid B Low
51. P0250 Turbocharger Wastegate Solenoid B High
52. P0251 Injection Pump Fuel Metering Control "A" Malfunction (Cam/Rotor/Injector)
53. P0252 Injection Pump Fuel Metering Control "A" Range/Performance (Cam/Rotor/Injector)
54. P0253 Injection Pump Fuel Metering Control "A" Low (Cam/Rotor/Injector)
55. P0254 Injection Pump Fuel Metering Control "A" High (Cam/Rotor/Injector)
56. P0255 Injection Pump Fuel Metering Control "A" Intermittent (Cam/Rotor/Injector)
57. P0256 Injection Pump Fuel Metering Control "B" Malfunction (Cam/Rotor/Injector)
58. P0257 Injection Pump Fuel Metering Control "B" Range/Performance Injector)
59. P0258 Injection Pump Fuel Metering Control "B" Low (Cam/R
60. P0259 Injection Pump Fuel Metering Control "B" High (Cam/R
61. P0260 Injection Pump Fuel Metering Control "B" Intermittent Injector)
62. P0261 Cylinder I Injector Circuit Low
63. P0262 Cylinder I Injector Circuit High
64. P0263 Cylinder I Contribution/Balance Fault
65. P0264 Cylinder 2 Injector Circuit Low
66. P0265 Cylinder 2 Injector Circuit High
67. P0266 Cylinder 2 Contribution/Balance Fault
68. P0267 Cylinder 3 Injector Circuit Low
69. P0268 Cylinder 3 Injector Circuit High
70. P0269 Cylinder 3 Contribution/Balance Fault
71. P0270 Cylinder 4 Injector Circuit Low
72. P0271 Cylinder 4 Injector Circuit High
73. P0272 Cylinder 4 Contribution/Balance Fault
74. P0273 Cylinder 5 Injector Circuit Low
75. P0274 Cylinder 5 Injector Circuit High
76. P0275 Cylinder S Contribution/Balance Fault
77. P0276 Cylinder 6 Injector Circuit Low
78. P0277 Cylinder 6 Injector Circuit High
79. P0278 Cylinder 6 Contribution/Balance Fault
80. P0279 Cylinder 7 Injector Circuit Low
81. P0280 Cylinder 7 Injector Circuit High
82. P0281 Cylinder 7 Contribution/Balance Fault
83. P0282 Cylinder 8 Injector Circuit Low
84. P0283 Cylinder 8 Injector Circuit High
85. P0284 Cylinder 8 Contribution/Balance Fault
86. P0285 Cylinder 9 Injector Circuit Low
87. P0286 Cylinder 9 Injector Circuit High
88. P0287 Cylinder 9 Contribution/Balance Fault
89. P0288 Cylinder 10 Injector Circuit Low
90. P0289 Cylinder 10 Injector Circuit High
91. P0290 Cylinder 10 Contribution/Balance Fault
92. P0291 Cylinder 11 Injector Circuit Low
93. P0292 Cylinder 11 Injector Circuit High
94. P0293 Cylinder 11 Contribution/Balance Fault
95. P0294 Cylinder 12 Injector Circuit Low
96. P0295 Cylinder 12 Injector Circuit High
97. P0296 Cylinder 12 Contribution/Range Fault

DTC Codes - P0300-P0399 – Ignition System or Misfire

1. P0300 Random/Multiple Cylinder Misfire Detected
2. P0301 Cylinder 1 Misfire Detected
3. P0302 Cylinder 2 Misfire Detected
4. P0303 Cylinder 3 Misfire Detected
5. P0304 Cylinder 4 Misfire Detected
6. P0305 Cylinder 5 Misfire Detected
7. P0306 Cylinder 6 Misfire Detected
8. P0307 Cylinder 7 Misfire Detected
9. P0308 Cylinder 8 Misfire Detected
10. P0309 Cylinder 9 Misfire Detected
11. P0311 Cylinder 11 Misfire Detected
12. P0312 Cylinder 12 Misfire Detected
13. P0320 Ignition/Distributor Engine Speed Input Circuit Malfunction
14. P0321 Ignition/Distributor Engine Speed Input Circuit Range/Performance
15. P0322 Ignition/Distributor Engine Speed Input Circuit No Signal
16. P0323 Ignition/Distributor Engine Speed Input Circuit Intermittent
17. P0325 Knock Sensor 1 Circuit Malfunction (Bank I or Single Sensor)
18. P0326 Knock Sensor 1 Circuit Range/Performance (Bank 1 or Single Sensor)
19. P0327 Knock Sensor 1 Circuit Low Input (Bank I or Single Sensor)
20. P0328 Knock Sensor 1 Circuit High Input (Bank I or Single Sensor)
21. P0329 Knock Sensor 1 Circuit Intermittent (Bank 1 or Single Sensor)
22. P0330 Knock Sensor 2 Circuit Malfunction (Bank 2)
23. P0331 Knock Sensor 2 Circuit Range/Performance (Bank 2)
24. P0332 Knock Sensor 2 Circuit Low Input (Bank 2)
25. P0333 Knock Sensor 2 Circuit High Input (Bank 2)
26. P0334 Knock Sensor 2 Circuit Intermittent (Bank 2)
27. P0335 Crankshaft Position Sensor A Circuit Malfunction
28. P0336 Crankshaft Position Sensor A Circuit Range/Performance
29. P0337 Crankshaft Position Sensor A Circuit Low Input
30. P0338 Crankshaft Position Sensor A Circuit High Input
31. P0339 Crankshaft Position Sensor A Circuit Intermittent
32. P0340 Camshaft Position Sensor Circuit Malfunction
33. P0341 Camshaft Position Sensor Circuit Range/Performance
34. P0342 Camshaft Position Sensor Circuit Low Input
35. P0343 Camshaft Position Sensor Circuit High Input
36. P0344 Camshaft Position Sensor Circuit Intermittent
37. P0350 Ignition Coil Primary/Secondary Circuit Malfunction
38. P0351 Ignition Coil A Primary/Secondary Circuit Malfunction
39. P0352 Ignition Coil B Primary/Secondary Circuit Malfunction
40. P0353 Ignition Coil C Primary/Secondary Circuit Malfunction
41. P0354 Ignition Coil D Primary/Secondary Circuit Malfunction
42. P0355 Ignition Coil E Primary/Secondary Circuit Malfunction
43. P0356 Ignition Coil F Primary/Secondary Circuit Malfunction
44. P0357 Ignition Coil G Primary/Secondary Circuit Malfunction
45. P0358 Ignition Coil H Primary/Secondary Circuit Malfunction
46. P0359 Ignition Coil I Primary/Secondary Circuit Malfunction
47. P0360 Ignition Coil J Primary/Secondary Circuit Malfunction
48. P0361 Ignition Coil K Primary/Secondary Circuit Malfunction
49. P0362 Ignition Coil L Primary/Secondary Circuit Malfunction
50. P0370 Timing Reference High Resolution Signal A Malfunction
51. P0371 Timing Reference High Resolution Signal A Too Many Pulses
52. P0372 Timing Reference High Resolution Signal A Too Few Pulses
53. P0373 Timing Reference High Resolution Signal A Intermittent/Erratic Pulses
54. P0374 Timing Reference High Resolution Signal A No Pulses
55. P0375 Timing Reference High Resolution Signal B Malfunction
56. P0376 Timing Reference High Resolution Signal B Too Many Pulses
57. P0377 Timing Reference High Resolution Signal B Too Few Pulses
58. P0378 Timing Reference High Resolution Signal B Intermittent/Erratic Pulses
59. P0379 Timing Reference High Resolution Signal B No Pulses
60. P0380 Glow Plug/Heater Circuit "A" Malfunction
61. P0381 Glow Plug/Heater Indicator Circuit Malfunction
62. P0382 Exhaust Gas Recirculation Flow Malfunction
63. P0385 Crankshaft Position Sensor B Circuit Malfunction
64. P0386 Crankshaft Position Sensor B Circuit Range/Performance
65. P0387 Crankshaft Position Sensor B Circuit Low Input
66. P0388 Crankshaft Position Sensor B Circuit High Input
67. P0389 Crankshaft Position Sensor B Circuit Intermittent

DTC Codes - P0400-P0499 – Auxiliary Emissions Controls

1. P0400 Exhaust Gas Recirculation Flow Malfunction
2. P0401 Exhaust Gas Recirculation Flow Insufficient Detected
3. P0402 Exhaust Gas Recirculation Flow Excessive Detected
4. P0403 Exhaust Gas Recirculation Circuit Malfunction
5. P0404 Exhaust Gas Recirculation Circuit Range/Performance
6. P0405 Exhaust Gas Recirculation Sensor A Circuit Low
7. P0406 Exhaust Gas Recirculation Sensor A Circuit High
8. P0407 Exhaust Gas Recirculation Sensor B Circuit Low
9. P0408 Exhaust Gas Recirculation Sensor B Circuit High
10. P0410 Secondary Air Injection System Malfunction
11. P0411 Secondary Air Injection System Incorrect Flow Detected
12. P0412 Secondary Air Injection System Switching Valve A Circuit Malfunction
13. P0413 Secondary Air Injection System Switching Valve A Circuit Open
14. P0414 Secondary Air Injection System Switching Valve A Circuit Shorted
15. P0415 Secondary Air Injection System Switching Valve B Circuit Malfunction
16. P0416 Secondary Air Injection System Switching Valve B Circuit Open
17. P0417 Secondary Air Injection System Switching Valve B Circuit Shorted
18. P0418 Secondary Air Injection System Relay ‘A" Circuit Malfunction
19. P0419 Secondary Air Injection System Relay "B’ Circuit Malfunction
20. P0420 Catalyst System Efficiency Below Threshold (Bank 1)
21. P0421 Warm Up Catalyst Efficiency Below Threshold (Bank 1)
22. P0422 Main Catalyst Efficiency Below Threshold (Bank 1)
23. P0423 Heated Catalyst Efficiency Below Threshold (Bank 1)
24. P0424 Heated Catalyst Temperature Below Threshold (Bank 1)
25. P0430 Catalyst System Efficiency Below Threshold (Bank 2)
26. P0431 Warm Up Catalyst Efficiency Below Threshold (Bank 2)
27. P0432 Main Catalyst Efficiency Below Threshold (Bank 2)
28. P0433 Heated Catalyst Efficiency Below Threshold (Bank 2)
29. P0434 Heated Catalyst Temperature Below Threshold (Bank 2)
30. P0440 Evaporative Emission Control System Malfunction
31. P0441 Evaporative Emission Control System Incorrect Purge Flow
32. P0442 Evaporative Emission Control System Leak Detected (small leak)
33. P0443 Evaporative Emission Control System Purge Control Valve Circuit
34. P0444 Evaporative Emission Control System Purge Control Valve Circuit
35. P0445 Evaporative Emission Control System Purge Control Valve Circuit Shorted
36. P0446 Evaporative Emission Control System Vent Control Circuit Malfunction
37. P0447 Evaporative Emission Control System Vent Control Circuit Open
38. P0448 Evaporative Emission Control System Vent Control Circuit Shorted
39. P0449 Evaporative Emission Control System Vent Valve/Solenoid Circuit Malfunction
40. P0450 Evaporative Emission Control System Pressure Sensor Malfunction
41. P0451 Evaporative Emission Control System Pressure Sensor Range/Performance
42. P0452 Evaporative Emission Control System Pressure Sensor Low Input
43. P0453 Evaporative Emission Control System Pressure Sensor High Input
44. P0454 Evaporative Emission Control System Pressure Sensor Intermittent
45. P0455 Evaporative Emission Control System Leak Detected (gross leak)
46. P0460 Fuel Level Sensor Circuit Malfunction
47. P0461 Fuel Level Sensor Circuit Range/Performance
48. P0462 Fuel Level Sensor Circuit Low Input
49. P0463 Fuel Level Sensor Circuit High Input
50. P0464 Fuel Level Sensor Circuit Intermittent
51. P0465 Purge Flow Sensor Circuit Malfunction
52. P0466 Purge Flow Sensor Circuit Range/Performance
53. P0467 Purge Flow Sensor Circuit Low Input
54. P0468 Purge Flow Sensor Circuit High Input
55. P0469 Purge Flow Sensor Circuit Intermittent
56. P0470 Exhaust Pressure Sensor Malfunction
57. P0471 Exhaust Pressure Sensor Range/Performance
58. P0472 Exhaust Pressure Sensor Low
59. P0473 Exhaust Pressure Sensor High
60. P0474 Exhaust Pressure Sensor Intermittent
61. P0475 Exhaust Pressure Control Valve Malfunction
62. P0476 Exhaust Pressure Control Valve Range/Performance
63. P0477 Exhaust Pressure Control Valve Low
64. P0478 Exhaust Pressure Control Valve High
65. P0479 Exhaust Pressure Control Valve Intermittent
66. P0480 Cooling Fan I Control Circuit Malfunction
67. P0481 Cooling Fan 2 Control Circuit Malfunction
68. P0482 Cooling Fan 3 Control Circuit Malfunction
69. P0483 Cooling Fan Rationality Check Malfunction
70. P0484 Cooling Fan Circuit Over Current
71. P0485 Cooling Fan Power/Ground Circuit Malfunction

DTC Codes - P0500-P0599 – Vehicle Speed Controls and Idle Control System

1. P0500 Vehicle Speed Sensor Malfunction
2. P0501 Vehicle Speed Sensor Range/Performance
3. P0502 Vehicle Speed Sensor Low Input
4. P0503 Vehicle Speed Sensor Intermittent/Erratic/High
5. P0505 Idle Control System Malfunction
6. P0506 Idle Control System RPM Lower Than Expected
7. P0507 Idle Control System RPM Higher Than Expected
8. P0510 Closed Throttle Position Switch Malfunction
9. P0520 Engine Oil Pressure Sensor/Switch Circuit Malfunction
10. P0521 Engine Oil Pressure Sensor/Switch Circuit Range/Performance
11. P0522 Engine Oil Pressure Sensor/Switch Circuit Low Voltage
12. P0523 Engine Oil Pressure Sensor/Switch Circuit High Voltage
13. P0530 A/C Refrigerant Pressure Sensor Circuit Malfunction
14. P0531 A/C Refrigerant Pressure Sensor Circuit Range/Performance
15. P0532 A/C Refrigerant Pressure Sensor Circuit Low Input
16. P0533 A/C Refrigerant Pressure Sensor Circuit High Input
17. P0534 Air Conditioner Refrigerant Charge Loss
18. P0550 Power Steering Pressure Sensor Circuit Malfunction
19. P0551 Power Steering Pressure Sensor Circuit Range/Performance
20. P0552 Power Steering Pressure Sensor Circuit Low Input
21. P0553 Power Steering Pressure Sensor Circuit High Input
22. P0554 Power Steering Pressure Sensor Circuit Intermittent
23. P0560 System Voltage Malfunction
24. P0561 System Voltage Unstable
25. P0562 System Voltage Low
26. P0563 System Voltage High
27. P0565 Cruise Control On Signal Malfunction
28. P0566 Cruise Control Off Signal Malfunction
29. P0567 Cruise Control Resume Signal Malfunction
30. P0568 Cruise Control Set Signal Malfunction
31. P0569 Cruise Control Coast Signal Malfunction
32. P0570 Cruise Control Accel Signal Malfunction
33. P0571 Cruise Control/Brake Switch A Circuit Malfunction
34. P0572 Cruise Control/Brake Switch A Circuit Low
35. P0573 Cruise Control/Brake Switch A Circuit High
36. P0574 Cruise Control Related Malfunction
37. P0575 Cruise Control Related Malfunction
38. P0576 Cruise Control Related Malfunction
39. P0576 Cruise Control Related Malfunction
40. P0578 Cruise Control Related Malfunction
41. P0579 Cruise Control Related Malfunction
42. P0580 Cruise Control Related Malfunction

DTC Codes - P0600-P0699 – Computer Output Circuit

1. P0600 Serial Communication Link Malfunction
2. P0601 Internal Control Module Memory Check Sum Error
3. P0602 Control Module Programming Error
4. P0603 Internal Control Module Keep Alive Memory (KAM) Error
5. P0604 Internal Control Module Random Access Memory (RAM) Error
6. P0605 Internal Control Module Read Only Memory (ROM) Error
7. P0606 PCM Processor Fault
8. P0608 Control Module VSS Output "A’ Malfunction
9. P0609 Control Module VSS Output "B" Malfunction
10. P0620 Generator Control Circuit Malfunction
11. P0621 Generator Lamp "L" Control Circuit Malfunction
12. P0622 Generator Field "F" Control Circuit Malfunction
13. P0650 Malfunction Indicator Lamp (MIL) Control Circuit Malfunction
14. P0654 Engine RPM Output Circuit Malfunction
15. P0655 Engine Hot Lamp Output Control Circuit Malfunction
16. P0656 Fuel Level Output Circuit Malfunction

DTC Codes - P0700-P0899 – Transmission

1. P0700 Transmission Control System Malfunction
2. P0701 Transmission Control System Range/Performance
3. P0702 Transmission Control System Electrical
4. P0703 Torque Converter/Brake Switch B Circuit Malfunction
5. P0704 Clutch Switch Input Circuit Malfunction
6. P0705 Transmission Range Sensor Circuit malfunction (PRNDL Input)
7. P0706 Transmission Range Sensor Circuit Range/Performance
8. P0707 Transmission Range Sensor Circuit Low Input
9. P0708 Transmission Range Sensor Circuit High Input
10. P0709 Transmission Range Sensor Circuit Intermittent
11. P0710 Transmission Fluid Temperature Sensor Circuit Malfunction
12. P0711 Transmission Fluid Temperature Sensor Circuit Range/Performance
13. P0712 Transmission Fluid Temperature Sensor Circuit Low Input
14. P0713 Transmission Fluid Temperature Sensor Circuit High Input
15. P0714 Transmission Fluid Temperature Sensor Circuit Intermittent
16. P0715 Input/Turbine Speed Sensor Circuit Malfunction
17. P0716 Input/Turbine Speed Sensor Circuit Range/Performance
18. P0717 Input/Turbine Speed Sensor Circuit No Signal
19. P0718 Input/Turbine Speed Sensor Circuit Intermittent
20. P0719 Torque Converter/Brake Switch B Circuit Low
21. P0720 Output Speed Sensor Circuit Malfunction
22. P0721 Output Speed Sensor Range/Performance
23. P0722 Output Speed Sensor No Signal
24. P0723 Output Speed Sensor Intermittent
25. P0724 Torque Converter/Brake Switch B Circuit High
26. P0725 Engine Speed input Circuit Malfunction
27. P0726 Engine Speed Input Circuit Range/Performance
28. P0727 Engine Speed Input Circuit No Signal
29. P0728 Engine Speed Input Circuit Intermittent
30. P0730 Incorrect Gear Ratio
31. P0731 Gear I Incorrect ratio
32. P0732 Gear 2 Incorrect ratio
33. P0733 Gear 3 Incorrect ratio
34. P0734 Gear 4 Incorrect ratio
35. P0735 Gear 5 Incorrect ratio
36. P0736 Reverse incorrect gear ratio
37. P0740 Torque Converter Clutch Circuit Malfunction
38. P0741 Torque Converter Clutch Circuit Performance or Stuck Off
39. P0742 Torque Converter Clutch Circuit Stock On
40. P0743 Torque Converter Clutch Circuit Electrical
41. P0744 Torque Converter Clutch Circuit Intermittent
42. P0745 Pressure Control Solenoid Malfunction
43. P0746 Pressure Control Solenoid Performance or Stuck Off
44. P0747 Pressure Control Solenoid Stuck On
45. P0748 Pressure Control Solenoid Electrical
46. P0749 Pressure Control Solenoid Intermittent
47. P0750 Shift Solenoid A Malfunction
48. P0751 Shift Solenoid A Performance or Stuck Off
49. P0752 Shift Solenoid A Stuck On
50. P0753 Shift Solenoid A Electrical
51. P0754 Shift Solenoid A Intermittent
52. P0755 Shift Solenoid B Malfunction
53. P0756 Shift Solenoid B Performance or Stock Off
54. P0757 Shift Solenoid B Stuck On
55. P0758 Shift Solenoid B Electrical
56. P0759 Shift Solenoid B Intermittent
57. P0760 Shift Solenoid C Malfunction
58. P076 I Shift Solenoid C Performance or Stuck Off
59. P0762 Shift Solenoid C Stuck On
60. P0763 Shift Solenoid C Electrical
61. P0764 Shift Solenoid C Intermittent
62. P0765 Shift Solenoid D Malfunction
63. P0766 Shift Solenoid D Performance or Stuck Off
64. P0767 Shift Solenoid D Stuck On
65. P0768 Shift Solenoid D Electrical
66. P0769 Shift Solenoid D Intermittent
67. P0770 Shift Solenoid E Malfunction
68. P0771 Shift Solenoid E Performance or Stuck Off
69. P0772 Shift Solenoid E Stuck On
70. P0773 Shift Solenoid E Electrical
71. P0774 Shift Solenoid E Intermittent
72. P0780 Shift Malfunction
73. P0781 1-2 Shift Malfunction
74. P0782 2-3 Shift Malfunction
75. P0783 3-4 Shift Malfunction
76. P0784 4-5 Shift Malfunction
77. P0785 Shift/Timing Solenoid Malfunction
78. P0786 Shift/Timing Solenoid Range/Performance
79. P0787 Shift/Timing Solenoid Low
80. P0788 Shift/Timing Solenoid High
81. P0789 Shift/Timing Solenoid Intermittent
82. P0790 Normal/Performance Switch Circuit Malfunction
83. P0801 Reverse Inhibit Control Circuit Malfunction
84. P0803 1-4 Upshift (Skip Shift) Solenoid Control Circuit Malfunction
85. P0804 1-4 Upshift (Skip Shift) Lamp Control Circuit Malfunction
